0.85 KW X-ray Body Scanner High Efficiency Airport Scanning Machine
| MOQ: | 1 |
| Price: | USD 60000~80000/SET |
| Standard Packaging: | Export Packing |
| Delivery Period: | 40-59DAYS |
| Payment Method: | T/T |
| Supply Capacity: | 5-12 UNITS/MONTH |
0.85 KW X-ray body scanner
,high efficiency airport scanning machine
,people screening X-ray machine
Vertical Micro-dose X-ray Security Body Scanner, JWS-X10DV Dual View
Functions:
The JWS X-Ray Full-Body Security Scanner conducts comprehensive security inspections in a privacy-preserving, non-intrusive fashion. Its innovative ultra-low radiation X-ray technology can expose threats concealed on a person’s exterior or hidden internally, making physical body searches by security staff unnecessary.
As a model with globally benchmarked scanning capacity, the JWS-X10 inspection device achieves steady identification of a wide spectrum of metal and non-metal dangerous articles. Detectable risks consist of guns, cartridges, ceramic edged tools, explosive agents, toxic fluids, mini electronic assemblies, powdery prohibited materials and various other hazardous objects.
Applications Scenarios:
Jails, Detection Facility, Mining, Rehabilitation Center, Public Security Department, Border Check, Customs, Airport, Railway Stations, Ports, Logistics and Warehousing, Government Buildings, Institutes, Meeting Centers
JWS-X10 X-ray Security Body Scanner Specifications (Dual View):
| Product | Micro- Dose X-ray Security Body Scanner, Dual View |
|---|---|
| Model: | JWS-X10 |
| Working Mode: | Vertical Scanning of Full and Selected Part of the Body of Inspected Person |
| Time per Scan: | 6-9 Seconds (Full Body Scanning) |
| Scanning Dosage per Scan: | From 0.2 to Max 4 μSv/scan ( Four Adjustable Modes againt Selection) |
| Liner Resolution: | 38 AWG/0.101mm metal wire |
| Scanning Height: | ≥1.9m |
| Scanning Width: | 1.0m |
| Spatial Resolution: | 1 mm |
| Image Resolution: | ≥ 2048 x 1024 PPI |
| Contrast Sensitivity: | 0.5% |
| Sizes: | ≤L 1.94m x W 1.4m x H2.5 m |
| Weight: | 710Kg (Excluding Console) |
| Rated Power: | 0.85 KW |
| Working Environment: | Tmp:0-+40℃; Humidity:5-95% |
| Voltage/Frequency | AC 127/220Vac, 50/60hz, or against client’s need |
| Installation Mode: | Complete Unit Installation |
Advantages - JWS-X10 X-ray Security Body Scanner
- Mobile Deployment
Thanks to the vertical scanning structure, the generator and detector of JWS-X10 X-ray Security Body Scanner are fixed on a single base, ensuring a fixed position. The device can be re-deployed as a whole without re-adjusting the beam path, allowing for quick redeployment. - Simpler Installation
Also thanks to the fixed position of the source and detector, JWS-X10 X-ray Security Body Scanner is shipped as a whole. During installation, simple cable connections are required only for fast deployment, eliminating the need for complex installation. - Small Footprint
The vertical scanning structure of JWS-X10 X-ray Security Body Scanner is much smaller, occupying about 3 square meters. Horizontal scanners, on the other hand, typically require 5-6 square meters. - Better Imaging Quality
Because the generator and detector of JWS-X10 X-ray Security Body Scanner are fixed in position, the beam path is always on the shortest, optimal path (as shown in the right figure). Compared to horizontal scanner, the penetration distance is significantly shortened. Under equivalent dose conditions, the detector of JWS-X10 X-ray Security Body Scanner receives a stronger signal, resulting in superior imaging quality. - Flexible Scanning Modes
Horizontal scanners are limited by their structural design and can only perform full-body or abdominal scans (requiring an additional source and detector ). Because the generator and detector of JWS-X10 X-ray Security Body Scanner are able to move up and down, scanning of the entire body or any specific area can be performed freely, without the need for additional generator and detectors. - Competitive Pricing
Due to unique vertical scanning structure, the detector size of JWS-X10 X-ray Security Body Scanner is significantly smaller than that of a horizontal model. This significantly reduces overall hardware costs. This is especially true for dual-view models. While horizontal perimeter probes require two sets of sources and detectors to achieve full-body and abdominal imaging, vertical scanner only require one set of generator and detector, significantly reducing costs. Compared to international brands, JWS-X10 X-ray Security Body Scanner is able to provide 30-50% or more advatanges!
